A peripheral power cable is used to connect the older IDE hard drives and cd/dvd drives to the power supply. These peripheral power connectors were the original power cables in a computer and were used most commonly for hard drives or cd drives.
.
In this way, what is the 4 pin 12v connector for?
The ATX 4 pin power supply connector is a standard motherboard power connector used to provide +12 VDC to the processor voltage regulator.
Also, what is the 4 pin connector on the power supply? The 4 pin power connector cable (12 volt cable) is designed to give extra power support to the motherboard. These two extra 12 volt cables (two yellow, two black) give the motherboard the option of accessing more power (through these cables). They generally help support the CPU but can be used for other things.
Consequently, what are the different power supply connectors?
Common Computer Power Supply Connectors
- 4 Pin Peripheral Power Connector.
- 4 Pin Peripheral to SATA Cable Assembly.
- SATA Power Connector.
- ATX 20 Pin Main Power Connector.
- ATX 24 Pin Main Power Connector.
- 4 Pin ATX +12V Power Connector.
- 8 Pin EPS +12V Power Connector.
- 6 Pin PCI Express Power Connector.
Are all power supply cords the same?
PSU CABLE COMPATIBILITY. Disclaimer: The only difference between Type 3 and Type 4 cables is the pinout of the 24-pin ATX cable; all other cables (SATA, PCIe, etc) are the same.
Related Question AnswersWhat are 4 pin Molex connectors used for?
The Molex connector is used for power connections for a disk drive in a computer as well as for other computer components such as CD-ROM's, graphic cards etc. The Molex connectors bring DC power to the drives inside a PC case.What does ATX mean?
ATX (Advanced Technology eXtended) is a motherboard and power supply configuration specification developed by Intel in 1995 to improve on previous de facto standards like the AT design.Can you use a 4 pin in a 8 pin?
The answer is yes. A 4-pin can be put, by itself, into an 8-pin CPU power socket and the machine boot up and run. It will give it what power it can, and if the CPU draws more than that, it will shut the system down. However, I've actively used 4-pin connectors in 8-pin CPU power sockets without having issues.What does the 24 pin connector do?
What is this connector for?| Name(s) | Function |
|---|---|
| 24 Pin 20+4 Pin | Main power connector for the motherboard. Notes: On a 20+4 Pin connector, four of the pins are on a separate block making it reverse compatible with the older motherboards that require only a 20 pin connector. |
What is the purpose of ATX power connector?
ATX power connectors are designed to connect a computer's power supply to an ATX motherboard. They are constructed of metal pins laid throughout a nylon matrix. The ATX power connector also offers another benefit. Unlike older power connectors , the ATX power connector is designed to only be plugged in one orientation.Do you need both 24 pin and 8 pin?
Both should be plugged in. You need both. The 24 pin is for the entire board (RAM, PCI/PCI-e slots, fan headers, Chipsets etc), the 8 pin is just for the CPU.Can a 4 pin ATX connector work on the 8 pin ATX motherboard?
Almost all current motherboards power their CPU with a 12 volt CPU power cable. There are two kinds: the 4 pin 12V cable and the 8 pin 12V cable. You can plug a 4 pin 12V cable into an 8 pin motherboard and it will sometimes work properly but other times it won't work at all or will burn/melt the connector.How many pins are there in the motherboard connector?
20 pinWhat are the 2 types of PSU cables?
Original PC main power cables| Pinout | ||
|---|---|---|
| Pin number | Wire color | Description |
| 2 | red | +5 volts or connector key |
| 3 | yellow | +12 volts |
| 4 | blue | -12 volts |
What are the 3 types of power supply?
There are three major kinds of power supplies: unregulated (also called brute force), linear regulated, and switching. The fourth type of power supply circuit called the ripple-regulated, is a hybrid between the “brute force” and “switching” designs, and merits a subsection to itself.What are peripheral cables for?
A peripheral power cable is used to connect the older IDE hard drives and cd/dvd drives to the power supply. These peripheral power connectors were the original power cables in a computer and were used most commonly for hard drives or cd drives.Where does the p6 connector go?
The P6 connector has multiple uses depending on the system. It can be used to power a graphics card (most new cards have their own power) or it can be plugged to the mainboard but thats rare, most motherboards use 4 or 8 pin plugs if they need extra power, leaving the P6's for the graphics card(s).Is a 6 2 pin the same as an 8 pin?
Long answer: Yes you can mix them anyway you prefer to. Some video cards have 6 Pin PCI Express power connectors and others have 8 Pin PCI Express power connectors. The 6+2 PCI Express power cable is made up of two pieces: a 6 pin piece, and a 2 pin piece.How much power does a SATA cable provide?
SATA power connectors has a total of 15 pins of which 9 are power pins (3 x 3.3V, 3 x 5V, 3 x 12V). Each pin can carry 1.5Amps for a total of 13.5Amps. BUT as there is as yet no use for the 3.3V pins the effective power available to drives is only 9Amps.What is a SATA cable?
SATA. Stands for "Serial Advanced Technology Attachment," or "Serial ATA." It is an interface used to connect ATA hard drives to a computer's motherboard. SATA cables can be as long as one meter, while PATA cables max out at 40cm.How many PCIe connectors do I need?
For the GPUs, you need 1 6 pin and 1 8 pin for EACH card, so 2 6 pins and 2 8 pins for a total of 4 connectors. Seasonic's X series has all the connectors you need, with the G series or the corsair HX series you'll need an adapter for the extra PCIe connectors.Which power supply cables do I need?
Power Cables- 24-pin power to motherboard (always required)
- 4/8-pin EPS12V power to CPU (always required)
- 6/8-pin power to video card (normally required)
- SATA power to storage devices (normally required)
- MOLEX power to accessories (optional)
- CPU fan & case fan power (required)
